ASSA ABLOY SW200 Door Operator
ASSA ABLOY SW200 (previously Besam) universal swing door operator.
The ASSA ABLOY SW200 is an intelligent, heavy duty, electromechanical swing door operator with an amazing capability to handle heavy doors. It is the ideal choice for applications with high demands on gentle and smooth operation in combination with strength and high traffic flow.
It compensates for stack pressure and wind load yet it remains easy to open manually.
ASSA ABLOY SW200 offers a unique 180 degree opening angle in both push and pull applications, and additionally it has an easy-to-use manual push force in power-off.
An optional embedded battery back-up and monitoring ensures operation even when the power is interrupted, while an intelligent locking function adds security.
ASSA ABLOY SW200 is suitable for applications such as: low energy and heavy duty, interior and exterior entrances, single and double leaf doors, fire doors (depending on national regulations), escape routes and push and pull applications.
Safety compliance
The ASSA ABLOY (previously Besam) SW200 complies with EN 1634-1, EN 16005, UL 325 and ANSI/BHMA A156.10, A156.19
ASSA ABLOY SW200 Swing Door Operator
Environmental Product Declaration
Available for downloads
ASSA ABLOY SW200
- Product ID: SW200
- Power supply: 100-240 V AC +10/-15%, 50/60 Hz, mains fuse max. 10A (building installation)
- Power consumption: max. 300 W
- Auxiliary voltage: 24 V DC, max. 700 mA
- Monitored battery backup unit: 24 V DC
- Electromechanical locking connection: 12 V DC, max. 1200 mA or 24 V DC, max. 600 mA
- Ambient temperature: -20 °C to +45 °C
- Relative humidity (non condensing) 95%
- Recommended max. door weight and door width inertia J: PUSH = 160 kgm², PULL = 80 kgm²
- Class of protection IP20
Product leaflet
Product drawings
