Energy-efficient
Combining good insulation with faster opening cycles to save energy.
Crawford OH1042S Fast Sectional Door
The Crawford OH1042S Fast Sectional Door is built for high-traffic environments where efficiency and speed are essential. With an impressive opening speed of 1 metre per second, it operates four times faster than standard doors, reducing downtime and improving workflow. This fast operation helps to limit heat loss and drafts, maintaining a controlled environment while boosting productivity and safety in busy warehouses, distribution centres, and manufacturing facilities.
Fast
Faster opening and closing minimizing air exchange during operation.
Insulated
Using panels with 42 mm insulation ensures great thermal separation.
Robust
Hardware and panels designed to meet the toughest environments.
Designed for durability and safety
This door is constructed with 42 mm insulation, providing excellent thermal separation to maintain a stable indoor temperature and improve energy efficiency. Its robust design ensures it can handle frequent use without compromising on reliability or performance. The integrated photo-cell light grid improves safety by automatically halting the door if it detects an obstruction, reducing the risk of accidents or damage during operation.
Customisable and connected for maximum convenience
Tailor the Crawford OH1042S to your specific requirements with various track systems, window options, and a selection of standard colours. You can also request a custom factory-painted finish to match your facility’s aesthetics. Equipped with ASSA ABLOY Insight, the door offers remote monitoring and control, allowing you to track performance, receive real-time alerts, and ensure optimal operation at all times.
- Standard size (WxH): Up to 5000 x 5000 mm
- Panel thickness: 42 mm
- Opening speed: 1.0 m/s
- Thermal transmittance: 1.0 W/(m²∙K)
- Wind load: EN 12424 Class 3
- Water penetration: EN 12425 Class 3
- Air permeability: EN 12426 Class 3
- Acoustic insulation: EN 10140-2 R - 25dB
- Track options: SL, HL, VL
- Windows: Optional
- Safety features: Photo-cell light grid for automatic stop if obstruction is detected
- ASSA ABLOY Insight IoT Gateway: Optional
- Material & finish: Steel/Aluminium with corrosion protection and 42mm polyurethane insulation
- Colours: Colza Yellow, Moss Green, Graphite Grey, Jet Black, and more
Crawford OH1042S OVERHEAD SECTIONAL DOOR
Environmental Product Declaration
Available for downloads
