ASSA ABLOY HS-Series Exterior High Speed Door

  • ASSA ABLOY

High wind load resistance and fast opening speeds with ASSA ABLOY high speed exterior doors.

ASSA ABLOY high speed exterior doors suit many different applications and offer excellent high wind-load resistance. Their unique design provides virtually perfect sealing, making the doors airtight and protecting your environment against drafts, humidity and dirt.

High opening- and closing-speed ensures maximum efficiency and helps you save energy.

ASSA ABLOY high speed exterior doors guarantee the safety of your personnel and equipment thanks to absence of stiffeners combined with a flexible curtain that moulds itself. A motor driven by a frequency converter makes Albany high-speed exterior doors extremely reliable. Soft starts and stops increase the longevity of the motor considerably.

All ASSA ABLOY high speed exterior doors are equipped with a break-away system. They are also self-repairing to reduce production downtime and maintenance.

ASSA ABLOY HS8010P

ASSA ABLOY HS8010P is a medium-sized high-speed door for outside, heavy-duty applications. To increase natural light, the door curtain can be equipped with windows or vision panels. A curtain with an increased static insulation is available as an option.

ASSA ABLOY HS8010PL

ASSA ABLOY HS8010PL is a large-sized high-speed door for outside, heavy-duty operations. It can be equipped with windows or vision panels to increase natural lighting. A curtain with an increased static insulation is available as an option.

ASSA ABLOY HS8020P

ASSA ABLOY HS8020P is a medium-sized high-speed door for outside applications with high wind loads. The door has excellent wind resistance, up to class 5 (EN12424). For better lighting, the door curtain can be equipped with windows or vision panels. A curtain with an increased static insulation is available as an option.

ASSA ABLOY HS8020PL

ASSA ABLOY HS8020PL is a large-sized high speed door for outside applications. Reinforced side guides secure easy opening and closing at high wind loads. To increase natural lighting, the door curtain can be equipped with windows or vision panels.

How to buy this product
Service and maintenance
A blue HS-series exterior door with two windows. Seen from the outside where it is a street and green trees. A blue HS-series exterior door with two windows. Seen from the outside where it is a street and green trees.
  • Revit
    ASSA ABLOY Material library HS8010P(ADSKLIB, 513 KB)
    ASSA ABLOY HPD HS8010PL(RFA, 984 KB)
    ASSA ABLOY Material library HS8020P(ADSKLIB, 325 KB)
    ASSA ABLOY HPD HS8020PL(RFA, 1 MB)
    ASSA ABLOY HPD HS8010P Revit 19(RFA, 2 MB)
    ASSA ABLOY HPD HS8010P Revit 22(RFA, 2 MB)
    ASSA ABLOY HPD HS8020P Revit 19(RFA, 2 MB)
    ASSA ABLOY HPD HS8010P Revit 22(RFA, 2 MB)
    Archicad
    ASSA ABLOY HPD HS8010P(LCF, 4 MB)
    ASSA ABLOY HPD HS8010PL(LCF, 4 MB)
  • ASSA ABLOY HS8010P high-speed door

    • Medium-sized, max. 5500 x 5500 mm
    • Heavy-duty operations
    • Galvanised steel construction
    • Unique direct door drive system
    • Opening speed up to 2,4 m/s

    ASSA ABLOY HS8010PL high-speed door

    • Large-sized, max. 9000 x 5500 mm
    • Heavy-duty operations
    • Galvanised steel construction
    • Unique direct door drive system
    • Opening speed up to 0,8 m/s

    ASSA ABLOY HS8020P high-speed door

    • Medium-sized, max. 5500 x 5500 mm
    • Heavy-duty operations
    • High wind loads, up to class 5
    • Galvanised steel construction
    • Unique direct door drive system
    • Opening speed up to 2,4 m/s

    ASSA ABLOY HS8020PL high-speed door

    • Large-sized, max. 8000 x 5500 mm
    • Heavy-duty operations
    • High wind loads, up to class 4
    • Galvanised steel construction
    • Unique direct door drive system
    • Opening speed up to 0,8 m/s
  • Product leaflet
    ASSA ABLOY HS8010P High speed door - en(PDF, 277 KB)
    ASSA ABLOY DCC50 and DCC55 - en(PDF, 255 KB)
    ASSA ABLOY HS8010PL High speed door - en(PDF, 304 KB)
    ASSA ABLOY HS8020PL High speed door - en(PDF, 281 KB)
    ASSA ABLOY HS8020P High speed door - en(PDF, 277 KB)
    Product datasheet
    ASSA ABLOY HS8020P High speed door - en(PDF, 1 MB)
    ASSA ABLOY HS8010P High speed door - en(PDF, 1 MB)
    ASSA ABLOY HS8020PL High speed door - en(PDF, 1 MB)
    ASSA ABLOY HS8010PL High speed door - en(PDF, 1 MB)
    Product specification text
    ASSA ABLOY HS8020P High speed door.doc(DOC, 232 KB)
    ASSA ABLOY HS8020PL High speed door.doc(DOC, 231 KB)
    ASSA ABLOY HS8010PL High speed door.doc(DOC, 230 KB)
    ASSA ABLOY HS8010P High speed door.doc(DOC, 236 KB)
    Product drawings
    DCC 50 and 55 steel housing dimensions(DXF, 3 MB)
    Assa Abloy DCC 50 and 55 INOX housing dimensions(DXF, 2 MB)
    Assa Abloy DCC 50 and 55 steel housing dimensions(PDF, 176 KB)
    Assa Abloy DCC 50 and 55 INOX housing dimensions(PDF, 166 KB)
    Assa Abloy DCC 50 and 55 plastic housing dimensions(DXF, 7 MB)
    Assa Abloy DCC 50 and 55 steel housing dimensions(DXF, 3 MB)
    Assa Abloy DCC 50 and 55 plastic housing dimensions(PDF, 248 KB)
    General Drawing Assa Abloy HS8020PL side guide section view(DWG, 272 KB)
    General Drawing Assa Abloy HS8020PL side guide section view(PDF, 111 KB)
    General Drawing Assa Abloy HS9010P HS8010P HS8020P built in dimensions larger 4000mm(DWG, 202 KB)
    General Drawing Assa Abloy HS9010P HS8010P HS8020P built in dimensions larger 4000mm(PDF, 117 KB)
    General Drawing Assa Abloy HS9010P HS8010P HS8020P built in dimensions reduced lintel(DWG, 500 KB)
    General Drawing Assa Abloy HS9010P HS8010P HS8020P built in dimensions reduced lintel(PDF, 166 KB)
    General Drawing Assa Abloy HS9010P HS8010P HS8020P built in dimensions smaller 4000mm(DWG, 203 KB)
    General Drawing Assa Abloy HS9010P HS8010P HS8020P built in dimensions smaller 4000mm(PDF, 117 KB)
    General Drawing Assa Abloy HS9010P HS8010P HS8020P built in dimensions without covers(DWG, 636 KB)
    General Drawing Assa Abloy HS9010P HS8010P HS8020P side guide section view(DWG, 252 KB)
    General Drawing Assa Abloy HS9010P HS8010P HS8020P built in dimensions without covers(PDF, 188 KB)
    General Drawing Assa Abloy HS9010P HS8010P HS8020P side guide section view(PDF, 104 KB)
    General Drawing Assa Abloy HS9010P HS8010P HS8020P side guide section view(DXF, 1 MB)
    General Drawing Assa Abloy HS9010PL HS8010PL HS8020PL built in dimensions with covers(DWG, 208 KB)
    General Drawing Assa Abloy HS9010PL HS8010PL HS8020PL built in dimensions with covers(PDF, 98 KB)
    General Drawing Assa Abloy HS9010PL HS8010PL HS8020PL built in dimensions without covers(DWG, 854 KB)
    General Drawing Assa Abloy HS9010PL HS8010PL HS8020PL built in dimensions without covers(PDF, 181 KB)
    General Drawing Assa Abloy HS9010PL HS8010PL side guide section view(DWG, 265 KB)
    General Drawing Assa Abloy HS9010PL HS8010PL side guide section view(PDF, 109 KB)
  • Product variationsDescription
    HS8010PHigh wind class - up to class 4, opening speed up to 2,4 m/s, size up to 5500x5500mm and break-away - an automatic reset system.
    HS8010PLDirect drive system, opening speed up to 1,4 m/s, size up to 9000x5500mm and break-away - an automatic reset system.
    HS8020PHigh wind class - up to class 5, opening speed up to 2,4 m/s, size up to 5500x5500mm and break-away - an automatic reset system.
    HS8020PLHigh wind class - up to class 4; opening speed up to 1,4 m/s, size up to 8000x5500mm and break-away - an automatic reset system.
