ASSA ABLOY SL500 Hurricane Resistant Sliding Door Resilience R104
ASSA ABLOY SL500 Resilience R104 – Extraordinary design pressures with expansive sizes
The ASSA ABLOY SL500 Resilience R104 is the definitive choice for hurricane-resistant automatic doors. The ASSA ABLOY SL500 Resilience R104 offers both strength and an array of options to meet all your needs in specifying, installing and owning hurricane rated sliding doors. Available in overall frame widths of up to 16’ for bi-parts, 9’ for single slides and overall frame heights of 104”, you get both strength and size. Coupled with an elevated ASTM F842-17 Forced Entry Resistance rating of Grade 25, the ASSA ABLOY SL500 Resilience R104 provides higher security than ever.
PSF Calculator - ASSA ABLOY SL500 Resilience R104
Select parameters below to determine your door package PSF.
FBO
FSL
BI-PART SLIDING DOOR
SINGLE SLIDE DOOR
Impact
Non Impact
Category D
Category E
Panic Device
No Panic Device
105.1
First row is the default value.
ASSA ABLOY SL500 Resilience R104 features
- PSF ratings varying from 80 to 125 (full impact) and 70 to 115 (non-impact) based on height, width, impact level and configuration
- Max overall frame width: 16’ bi-part, 9’ single slide
- Max overall frame height: 104”
- State of Florida approval
- Miami Dade approval
- Full Dry Glazed System
- Narrow Stile Design
- Compliance with NFPA 101 life safety code
- Category E option for essential facilities with optional surface mounted panic device rated for 80 PSF on FBO
- Grade 25 Forced Entry Resistance Rating
BIM Objects
Download these products as BIM objects here:
Downloads
Revit
